Diffuse Laser Cavity Reflector For Solid State Lasers
- Product Item : 10-013
- Category： Ceramic Laser Reflectors
- Material: Alumina ceramic
- Purity: 99%
- Surface: Full glazed
- Application: solid state lasers
Diffuse Laser Cavity Reflector For Solid State Lasers
The Diffuse Laser Cavity Reflector is used in solid state laser and CO2 laser system. It is made of high purity 99% alumina ceramic, with state diffuse reflection. We have the capability to custom design and manufacture the alumina ceramic laser cavity reflector. The product is in high precision, high reflectivity and long service life.Production Process
Raw material preparation → Forming → Repairing the blanks → Degreasing → Firing → Inspection → PackingProduct Features
• Fully glazed surface for maximum reflectivity and easy cleaning• Reflectivity reaches 97% at wavelengths of 600-1000nm
• Reflectivity exceeding 95% within the wavelength range of 380-1100nm
• The green body has appropriate porosity and high strength characteristics
• Diffuse reflection for better working performance
Spectrum of Reflectivity
Main Applications
• Laser Welding Machine,• Laser Cutting Machine,
• Laser Marking Machine,
• Medical Laser System
Working Temperature
Glazed: It is best not to keep the working temperature of glazed ceramic reflectors above 300℃ for a long time, otherwise crystallization may occur.Non glazed: The working temperature of non glazed ceramic reflectors can be 1200℃.
